xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
495
Parameters
<map_name 16> - Enter the route map name.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create a route map named map1:
DGS-3120-24TC:admin#create route_map map1
Command: create route_map map1
Success.
45-6 config route_map
Description
This command is used to configure the route map. A route map can have multiple rule entries,
each with a different sequence number. When creating a route map, a sequence ID, 10, will be
add to the route map. If the sequence number is not specified, it will be automatically given. The
automatically given sequence number will be multiple of 10. If permit/deny is not specified, permit
is applied.
Format
config route_map <map_name 16> [[add | delete] sequence <value 1-65535 > {[deny |
permit]} | sequence <value 1-65535> [match [add | delete] [ip [next_hop | address]
<list_name 16> | metric <uint 0-4294967294> | route_type [internal | external | type_1 |
type_2] | interface <ipif_name 12> | route_source <list_name 16>] | set [add | delete]
[next_hop [<ipaddr>] | metric <uint 0-4294967294> | metric_type [type_1 | type_2]]]]
Parameters
<map_name 16> - Enter the name of the route map.
add - Add the specified sequence.
delete - Delete the specified sequence.
sequence - Specify the sequence.
<value 1-65535 > - Enter the sequence number for the route map rule.
deny - (Optional) Deny the route if the rule is matched.
permit- (Optional) Permit the route if the rule is matched.
sequence - Specify the sequence.
<value 1-65535> - Enter the sequence number for the route map rule.
match - Specify to configure the macth rules.
add - Add a match rule.
delete - Delete a match rule.
ip - Specify to match IP information.
next_hop - Specify to match the next hop of the routes.
address - Specify to match the routes.
