D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
811
Example
To show the PIM6 neighbors:
DGS-3120-24TC:admin#show pim6 neighbor
Command: show pim6 neighbor
PIM6 Neighbor Address Table
Interface Neighbor Address
-------------- ----------------
System FE80::200:FF:FE26:66D0
n1 FE80::200:FF:FE26:66D1
Total Entries : 2
DGS-3120-24TC:admin#
To show the PIM6 neighbors of interface “n20”:
DGS-3120-24TC:admin# show pim6 neighbor ipif n20
Command: show pim6 neighbor ipif n20
Neighbor Info on Interface n20
----------------------------------------------------
Neighbor Address : FE80::11FF:4CD8
Neighbor Up Time : 00:00:50
Neighbor Expiry Time : 00:01:50
Neighbor DR Priority Present : True
Neighbor DR Priority : 1
Total Entries : 1
DGS-3120-24TC:admin#
81-12 show pim6 mroute
Description
This command is used to display the multicast routing information generated by PIM6.
Format
show pim6 mroute {group <ipv6addr> {source <ipv6addr>}}
Parameters
group - (Optional) Specify the IPv6 multicast group address to be displayed.
<ipv6addr> - Enter the IPv6 address.
source - (Optional) Specify the IPv6 source address to be displayed.
<ipv6addr> - Enter the IPv6 address.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
