D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
812
Restrictions
None.
Example
To show the whole IPv6 multicast routing table generated on the Switch:
DGS-3120-24TC:admin#show pim6 mroute
Command: show pim6 mroute
Total (*,*,RP) Entries : 0
Total (*,G) Entries : 1
Total (S,G) Entries : 2
Total (S,G,rpt) Entries : 1
Group : FF13::100
Source : * Upstream: n1
Outgoing : n10 n30
Group : FF13::100
Source : 2001::1111 Upstream: n2
Outgoing: n10
Group : FF13::102
Source : 2001::3F6D Upstream: n2
Outgoing: n20
Group : FF13::100
Source : 2001::1111 rpt, Upstream: n1
RP Address: 3FFE:10:10::153
Outgoing : -
Total Entries: 4
DGS-3120-24TC:admin#
81-13 show pim6 mroute star_g
Description
This command is used to display the multicast routing information for (*, G) entries generated by
PIM6.
Format
show pim6 mroute star_g {group <ipv6addr> {ipif <ipif_name 12>}}
Parameters
group - (Optional) Specify the IPv6 multicast group address to be displayed.
<ipv6addr> - Enter the IPv6 address.
ipif - (Optional) Specify the IPv6 interface to be displayed.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
