D-Link xStack DGS-3120 Series User Manual

xStack
®
DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch CLI Reference Guide
813
<ipif_name 12> - Enter the IPv6 interface name.
Restrictions
None.
Example
To show the whole IPv6 multicast routing table of (*, G) generated on the switch:
DGS-3120-24TC:admin#show pim6 mroute star_g
Command: show pim6 mroute star_g
(*, G) Entry Table
-------------------------
Group : FF13::100
Upstream : n2
RP Address : 3FFE:10:10::153
Group : FF13::101
Upstream : n2
RP Address : 3FFE:10:10::153
Group : FF13::102
Upstream : n2
RP Address : 3FFE:10:10::153
Total Entries: 3
DGS-3120-24TC:admin#
81-14 show pim6 mroute s_g
Description
This command is used to display the multicast routing information for (S, G) or (S, G, rpt) entries
generated by PIM6.
Format
show pim6 mroute s_g {rpt} {group <ipv6addr> source <ipv6addr> {ipif <ipif_name 12>}}
Parameters
rpt - (Optional) Specify the (S, G, rpt) entry.
group - (Optional) Specify the IPv6 multicast group address to be displayed.
<ipv6addr> - Enter the IPv6 address.
source - (Optional) Specify the IPv6 source address to be displayed.
<ipv6addr> - Enter the IPv6 address.
ipif - (Optional) Specify to the IPv6 interface name to be displayed.
<ipif_name 12> - Enter the IPv6 interface name.

D-Link xStack DGS-3120 Series Specifications

General

MAC Address Table	16K entries
Ports	10/100/1000BASE-T ports
VLANs	4094
Jumbo Frame	Up to 9KB
Power Supply	Internal power supply (depending on model)
Power over Ethernet (PoE)	No
Layer 3 Features	RIP
Quality of Service (QoS)	8 queues per port, DiffServ
Security Features	ACLs
Management	Web-based, CLI, SNMP
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
SFP Ports	Combo 10/100/1000BASE-T/SFP ports and/or dedicated SFP/SFP+ ports (depending on model)
