Restrictions
None.
Example
To show all (S, G) route entries generated on the Switch:
DGS-3120-24TC:admin#show pim6 mroute s_g
Command: show pim6 mroute s_g
(S, G) Entry Table
------------------------
Group : FF13::100
Source : 2001::1111
Group : FF13::100
Source : 2001::2222
Group : FF13::200
Source : 2001::1111
Group : FF13::300
Source : 2001::1111
Total Entries: 4
DGS-3120-24TC:admin#
81-15 create pim6 static_rp group
Description
This command is used to create a static RP. In general, a static RP cannot override a dynamic RP.
If override_dynamic is configured, the static RP will override any dynamically learned RP.
Format
create pim6 static_rp group <ipv6networkaddr> rp <ipv6addr> {override_dynamic}
Parameters
<ipv6networkaddr> - Specify the multicast group network address for this static RP.
rp - Specify the IPv6 address to this static RP.
<ipv6addr> - Enter the IPv6 address.
override_dynamic - (Optional) Specify to enable static RP to override dynamically learned RP.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
