112 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2860:003
(P201.03)
Torque control: Default setpoint source
(Stnd. setpoints: Torque setp.src.)
•
From version 03.00
Selection of the standard setpoint source for operating mode "MS:
Torque mode".
•
The selected standard setpoint source is always active in the
operat
ing mode 0x6060 (P301.00)
= "MS: Torque mode [-1]" when
no setpoint change-over to another setpoint source via
corresponding triggers/functions is active.
1
Keypad
The setpoint is specified locally by the keypad.
•
Default setting: 0x2601:003 (P202.03)
•
Use the and navigation keys to change the keypad
setpoint (also during running operation).
2
Analog input 1
The setpoint is defined as analog signal via the analog input 1.
 Analog input 1

423
3
Analog input 2
The setpoint is defined as analog signal via the analog input 2.
 Analog input 2

427
5
Network
The setpoint is defined as process data object via the network.
 Configuring the network

166
11
Torque preset 1
For the setpoint selection, preset values can be parameterised and
selected.
 Setpoint source of preset setpoints  386
12
Torque preset 2
13 Torque preset 3
14
Torque preset 4
15
Torque preset 5
16
Torque preset 6
17
Torque preset 7
18 Torque preset 8
31
Segment preset 1
For the setpoint selection, the segment presets parameterised for the
"sequencer" function can be selected as well.
 Sequencer  327
32
Segment preset 2
33
Segment preset 3
34
Segment preset 4
35 Segment preset 5
36
Segment preset 6
37
Segment preset 7
38
Segment preset 8
50
Motor potentiometer
The setpoint is generated by the "motor potentiometer" function. This
function can be used as an alternative setpoint control which is
controlled via two signals: "MOP setpoint up" and "MOP setpoint
down".
 Motor potentiometer setpoint source (MOP)

392
