192 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2631:001
(P400.01)
Function list: Enable inverter
(Function list: Enable inverter)
Setting can only be changed if the inverter is
inhibi
ted.
Assignment of a trigger for the "Enable inverter" function.
Trigger = TRUE: The inverter is enabled (unless there is another cause
for inverter disable).
Trigger = FALSE: The inverter is disabled.
Notes:
This function must be set to TRUE to start the motor. Either via an
assigned digital input or by default setting "Constant TRUE [1]".
Changing to the inhibited state causes an immediate stop of the
motor, regardless of the stop method set in 0x2838:003 (P203.03).
The motor becomes torqueless and coasts down as a function of the
mass inertia of the machine.
The cause(s) that are active for the disabled state are shown in
0x282A:001 (P126.01).
0
Not connected
No trigger assigned (trigger is constantly FALSE).
1 Constant TRUE Trigger is constantly TRUE.
11
Digital input 1
State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideration.
12
Digital input 2
State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideration.
13
Digital input 3
State of X3/DI3, taking an inversion set in 0x2632:003 (P411.03) into
consideration.
14
Digital input 4
State of X3/DI4, taking an inversion set in 0x2632:004 (P411.04) into
consideration.
15
Digital input 5
State of X3/DI5, taking an inversion set in 0x2632:005 (P411.05) into
consideration.
50
Running
TRUE if inverter and start are enabled and output frequency > 0.2 Hz.
Otherwise FALSE.
51
Ready for operation
TRUE if inverter is ready for operation (no error active, no STO active
and DC-bus voltage ok). Otherwise FALSE.
53
Stop active
TRUE if inverter is enabled and motor is not started and output
frequency = 0.
54 Quick stop active TRUE if quick stop is active. Otherwise FALSE.
58
Device warning active
TRUE if warning is active. Otherwise FALSE.
A warning has no impact on the operating status of the inverter.
A warning is reset automatically if the cause has been eliminated.
59
Device fault active
TRUE if a fault is active. Otherwise FALSE.
In the event of a fault, the motor is brought to a standstill with the
quick stop ramp. The inverter is then disabled.
Exception: In case of a serious fault, the inverter is disabled
immedi
ately. The motor becomes torqueless (coasts).
The error state will be left automatically if the error condition is not
active anymore.
The restart behaviour after trouble can be configured. Automatic
restart

314
60 Heatsink temperature warning active TRUE if current heatsink temperature > warning threshold for
temperature monitoring. Otherwise FALSE.
Display of the current heatsink temperature in 0x2D84:001 (P117.01).
Setting of the warning threshold in 0x2D84:002.
69
Rotational direction reversed
TRUE if output frequency is negative. Otherwise FALSE.
70
Frequency threshold exceeded
TRUE if current output frequency > frequency threshold. Otherwise
FALSE.
Display of the current output frequency in 0x2DDD (P100.00).
Setting Frequency thresholdin 0x4005 (P412.00).
 Frequency threshold for "Frequency threshold exceeded" trigger 
421
71
Actual speed = 0
TRUE if current output frequency = 0 Hz (± 0.01 Hz), irrespective of the
operating mode. Otherwise FALSE.
Display of the current output frequency in 0x2DDD (P100.00).
78
Current limit reached
TRUE if current motor current ≥ maximum current. Otherwise FALSE.
Display of the present motor current in 0x2D88 (P104.00).
Setting for the maximum current in 0x6073 (P324.00).
