Name / value range / [default setting]
(P400.05)
Function list: Activate DC braking
(Function list: DC braking)
For further possible settings, see parameter
0x2631:001 (P400.01).
364
Assignment of a trigger for the "Activate DC braking" function.
Trigger = TRUE: Activate DC braking.
Trigger = FALSE: Deactivate DC braking.
CAUTION!
DC braking remains active as long as the trigger is set to TRUE.
DC braking
262
No trigger assigned (trigger is constantly FALSE).
(P203.01)
Start/stop configuration: Start method
(Start/stop confg: Start method)
Setting can only be changed if the inverter is
inhibi
Behaviour after start command.
After start command, the standard ramps are active.
Acceleration time 1 can be set in 0x2917 (P220.00).
Deceleration time 1 can be set in 0x2918 (P221.00).
After start command, the "DC braking" function is active for the time set
in 0x2B84:002 (P704.02).
DC braking
262
After the start command, the flying restart circuit is active.
The flying restart function makes it possible to restart a coasting motor
during operation without speed feedback. Synchronicity between the
inverter and motor is coordinated so that the transition to the rotating
motor is effected without jerk at the time of connection.
Flying restart circuit
311
(P203.03)
Start/stop configuration: Stop method
(Start/stop confg: Stop method)
Behaviour after the "Stop" command.
The motor becomes torqueless (coasts down to standstill).
The motor is brought to a standstill with deceleration time 1 (or
deceleration time 2, if activated).
Deceleration time 1 can be set in 0x2918 (P221.00).
Deceleration time 2 can be set in 0x291A (P223.00).
Frequency limits and ramp times
100
The motor is brought to a standstill with the deceleration time set for
the "Quick stop" function.
Deceleration time for quick stop can be set in 0x291C (P225.00).
The "quick stop" function can also be activated manually, for instance
via a digital input.
Quick stop
103
