Parameter
Name / value range / [default setting]
Info
0x2631:002
Function list: Run
(Function list: Run)
•
Setting can only be changed if the inverter is
inhibi
ted.
•
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run" function.
Function 1: Start / stop motor (default setting)
Function 1 is active if no further start commands (start forward/start
reverse) have been connected to triggers, no keypad control is active and
no network control is active.
Trigger = TRUE: Let motor rotate forward (CW).
Trigger = FALSE: Stop motor.
Notes to function 1:
•
If "Enable inverter" 0x2631:001 (P400.01) is set = "Constant TRUE
[1]",
the only permissible trigger for this function is a digital input in order
that the motor can be stopped again any time.
• The stop method can be selected in 0x2838:003 (P203.03).
• The function also serves to realise an automatic start after switch-on.
 Starting performance  97
Function 2: Start enable/stop motor
Function 2 is active if further start commands have been connected to
triggers, keypad control is active or network control is active.
Trigger = TRUE: Start commands of the active control source are
enabled.
Trigger = FALSE: Stop motor.
Notes to function 2:
•
If no separate start enable is required for the application, the trigger
"Constant TRUE [1]" must be set.
•
The stop method can be selected in 0x2838:003 (P203.03).
(P400.02)
11
Digital input 1
State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideration.
0x2631:004
(P400.04)
Function list: Reset fault
(Function list: Reset fault)
•
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Reset fault" function.
Trigger = FALSE↗TRUE (edge): Active error is reset (acknowledged) if
the
error condition is not active anymore and the error is resettable.
Trigger = FALSE: no action.
12
Digital input 2
State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideration.
0x2631:013
(P400.13)
Function list: Invert rotation
(Function list: Invert rotation)
•
Setting can only be changed if the inverter is
inhibi
ted.
•
For further possible settings, see parameter
0x2631:001 (P400.01).

364
Assignment of a trigger for the "Invert rotation" function.
Trigger = TRUE: the setpoint specified is inverted (i. e. the sign is inver-
ted).
Trigger = FALSE: no action / deactivate function again.
13
Digital input 3
State of X3/DI3, taking an inversion set in 0x2632:003 (P411.03) into
consideration.
0x2631:018
(P400.18)
Function list: Activate preset (bit 0)
(Function list: Setp: Preset b0)
•
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate preset (bit 0)" function.
Selection bit with the valency 20 for the bit-coded selection and activa-
tion of a parameterised setpoint (preset value).
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
14
Digital input 4
State of X3/DI4, taking an inversion set in 0x2632:004 (P411.04) into
consideration.
0x2631:019
(P400.19)
Function list: Activate preset (bit 1)
(Function list: Setp: Preset b1)
•
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate preset (bit 1)" function.
Selection bit with the valency 21 for the bit-coded selection and activa-
tion of a parameterised setpoint (preset value).
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
15 Digital input 5 State of X3/DI5, taking an inversion set in 0x2632:005 (P411.05) into
consideration.
