EPSON EPL-N3000/AcuLaser M4000N Revision C
Disassembly and Assembly Xero 242
Confidential
Installation
1. Put the FAN SUB into the DUCT FRONT, and secure it with the hook.
2. Move the DUCT FRONT mounted with the FAN SUB in the direction opposite to
the arrow, and install it to the frame.
3. Secure the DUCT FRONT with the three screws (silver, tapping with a collar,
8mm x1, gold, tapping, 8mm x2).
4. Connect the connector (P/J270) of the FAN SUB to the HARNESS ASSY LVPS.
5. Install the COVER FRONT. (p.172)
6. Install the COVER TOP, CONTROL PANEL. (p.170)
7. Install the 500 EXIT ASSY. (p.262)
8. Install the COVER EXIT 500. (p.261)
9. Install the COVER RIGHT. (p.168)
10. Install the COVER LEFT. (p.169)
11. Install the COVER REAR. (p.167)
12. Install the COVER REAR 500. (p.270)
C A U T I O N
Install the FAN SUB to the DUCT FRONT, with its label surface
inside and the harness placed in the orientation shown in the figure.
C A U T I O N
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
