Installation
1. While lifting the 150 FEEDER ASSY in the direction of the arrow (A), insert it
into the printer body, and engage the bosses on the left and right sides of the 150
FEEDER ASSY with the printer body.
2. Secure the 150 FEEDER ASSY to the printer body with the five screws (sliver,
with collars, with spring washers, 8mm).
3. Connect the connector (P/J243) of the CLUTCH REGI to the HARNESS ASSY
TRAY 1.
4. Connect the connector (P/J242) of the CLUTCH ASSY PH to the HARNESS
ASSY TRAY 1.
5. Connect the connector (P/J245) of the HARNESS ASSY TRAY 1 to the
HARNESS ASSY CHUTE.
6. With the BTR ASSY installed, install the CHUTE TRANSFER. (p.255)
7. Install the COVER REAR (AcuLaser M4000N). (p.379)
8. Install the FUSER ASSY. (p.253)
9. Install the COVER REAR 500. (p.270)
C H E C K
P O I N T
One of the screws for securing the 150 FEEDER ASSY also tightens
the EARTH PLATE BASE.
C H E C K
P O I N T
In the hole on the left side of the CHUTE TRANSFER, a screw need
not be tightened.
C H E C K
P O I N T
Pay attention to the difference between the two types of screws and
use them at their correct positions respectively.
