EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 470
Confidential
07-01-20 2082538 CLUTCH ASSY PH
07-01-21 2086911 CHUTE ASSY FDR2
07-01-23 1275198 COVER ACUTUATOR
07-01-27 1249169 CLUTCH ONEWAY NUDGER
07-01-28 1249170 CLUTCH ONEWAY FEED
07-01-32 1275683 CHUTE 550 LOWER
07-01-36 2086920 HARNESS ASSY TRAY2
07-01-37 2086907 HOLDER NO PAPER SENSOR
07-01-38 2021773 E.R.M. SENSOR
07-01-99 1246284 KIT ROLL ASSY FEED
08-01-01 2086921 ROS ASSY
08-01-02 2086922 HARNESS ASSY ROS
08-01-05 2087365 FAN SUB
08-01-06 2082553 GUIDE ASSY CRU L
08-01-09 1249173 SPRING SL
08-01-11 2082668 INTERLOCK S/W 24V
08-01-12 2082669 INTERLOCK S/W 5V
08-01-14 1249174 LEVER GUIDE
08-01-17 2084178 HARNESS ASSY FUSER 220V
08-01-18 2086923 LEVER FUSER LH
08-01-19 2086924 LEVER FUSER RH
08-01-20 2086925 FUSER ASSY 220V
08-01-21 1275221 BTR ASSY
08-01-22 1275222 CHUTE TRANSFER
08-01-23 2082555 PWBA ASSY ANT
08-01-24 2083944 HARNESS ASSY ANT
08-01-25 2082556 GUIDE ASSY CRU R
08-01-29 1246469 LEVER LINK
08-01-30 1249186 LINK GEAR 3
10-01-01 1275223 COVER EXIT 500
10-01-02 2086929 500 EXIT ASSY
10-01-03 2086930 CHUTE ASSY EXIT UPPER
Table 7-10. Main Unit
Ref. No Code Name
10-01-07 1275226 LINK GATE OCT
10-01-10 1275227 ACTUATOR FULL STACK
10-01-12 1275228 ROLL EXIT
10-01-13 1275229 GEAR 21
10-01-14 2086931 CHUTE ASSY EXIT LOWER
10-01-15 2086932 MOTOR ASSY EXIT
10-01-17 1275230 GEAR 16/49
10-01-18 1275231 GEAR 25-2
10-01-19 1275232 GEAR 25-1
10-01-20 1275233 GATE OCT EXIT
10-01-23 1275247 ROLLER PINCH EXIT
10-01-25 2021773 E.R.M. SENSOR
10-01-26 2021773 E.R.M. SENSOR
10-01-27 2086933 HARNESS ASSY EXIT SNR
10-01-29 1275735 CHUTE LOW ASSY
10-01-30 1275252 ROLL PINCH OCT
10-02-01 1275253 COVER REAR 500 ASSY
10-02-03 1275256 ROLL PINCH FU
10-02-04 1275257 SPRING PINCH FU
10-02-06 1275258 GATE FU
10-02-11 1275259 LEVER RATCH RIGHT
10-02-14 1275261 ROLL FU
10-02-17 1275263 LEVER GATE FU
10-02-21 1275264 COVER REAR 500
10-02-22 1275266 COVER DUP
10-02-23 1275269 STOPPER FSR
10-02-24 1275270 TRAY FU A3 ASSY
11-01-02 2086938 MAIN MOTOR
11-01-03 1275275 GEAR ASSY HOUSING
11-01-04 1246467 SPRING RELEASE
Table 7-10. Main Unit
Ref. No Code Name
