EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 471
Confidential

550-Sheet Cassette Unit A4 Universal
11-01-09 1277519 GEAR 9
11-01-10 1275276 GEAR ASSY PLATE
11-01-11 1275277 FOOT
Table 7-10. Main Unit
Ref. No Code Name
Table 7-11. 550-Sheet Cassette Unit A4 Universal
Ref. No Code Name
03-01-05 2082644 HARNESS ASSY FDR2
03-01-06 1246471 SPRING EARTH TOP
03-01-08 2082565 DRIVE ASSY OPT
03-01-17 2082683 MOTOR FEEDER
03-01-18 2082564 OPT ASSY SIZE
03-01-19 2087090 HARNESS ASSY SIZE FDR1
03-01-22 1276213 FOOT
03-01-23 1275671 FRAME BASE FRONT
03-01-25 1275673 COVER RE 550
03-01-26 2086974 HARNESS ASSY FDR5
03-01-29 2082566 LOW PAPER ASSY
03-01-30 2021773 E.R.M. SENSOR
03-01-31 1249194 ACTUATOR LOW PAPER
01-33 2086975 HARNESS LOW PAPER
01-34 2082569 PWBA FEEDER 550
01-35 2086976 HARNESS ASSY SIZE FDR2
01-36 2082686 HARNESS ASSY CLSNR2
01-37 2086977 HARNESS ASSY FDR MOT
01-38 1246472 JOINT FEEDER
01-39 1249171 LOCK CST L
03-02-01 2086978 550 FEEDER OPTION
03-02-02 2086911 CHUTE ASSY FDR2
03-02-03 1275193 SUPPORT ASSY NUDGER
03-02-06 1275194 ACUTUATOR NO PAPER
03-02-07 1249110 GEAR IDLER NUDGER
03-02-10 1275195 ROLL ASSY GEAR NUDGER
03-02-13 1249170 CLUTCH ONEWAY FEED
03-02-14 1275679 ROLL ASSY TURN
03-02-15 1249169 CLUTCH ONEWAY NUDGER
03-02-19 1275198 COVER ACUTUATOR
03-02-21 2082538 CLUTCH ASSY PH
