EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 472
Confidential
03-02-22 2082538 CLUTCH ASSY PH
03-02-24 1275681 CHUTE OUT ASSY
03-02-28 1249308 ROLL PINCH TURN
02-31 2086980 HARNESS ASSY CLSNR1
02-32 2086907 HOLDER NO PAPER SENSOR
02-33 2021773 E.R.M. SENSOR
02-34 1275683 CHUTE 550 LOWER
02-99 1246284 KIT ROLL ASSY FEED
03-03-01 1275134 COVER CST
03-03-03 1246285 FRICTION CLUTCH
03-03-06 1249129 SPRING RETARD
03-03-07 1249109 GEAR PB L
03-03-08 1249140 GEAR BTM ONEWAY
03-03-10 1275136 PLATE ASSY BTM
03-03-11 1275183 GUIDE ASSY SD L 550
03-03-13 1275184 GUIDE ASSY SD R 550
03-03-15 1249143 GEAR LOCK ONEWAY
03-03-18 1275185 SPRING BTM UP 550
03-03-19 1249329 PLATE GEAR LOCK 550
03-03-20 1249103 GEAR PB R
03-03-21 1249330 RACK BTM LOCK 550
03-03-22 1275186 COVER BTM UP 550
03-03-23 1249104 GEAR LOCK PINION
03-03-24 1249133 SPRING BTM LOCK
03-03-25 1275187 GEAR BTM ROCK
03-03-26 1249134 GEAR LEVER LOCK
03-03-27 1249135 LEVER BTM LOCK
03-03-28 1249137 SPRING STOPPER GEAR
03-03-29 1249136 STOPPER GEAR
03-36 1249331 GUIDE INDICATOR 3
03-40 1275140 RACK SIZE
03-41 1275188 HANDLE EXTENSION 550
Table 7-11. 550-Sheet Cassette Unit A4 Universal
Ref. No Code Name
03-43 1275189 GUIDE ASSY END 550
03-45 1249334 LINK SW SIZE 1-550
03-46 1249333 LINK SW SIZE 2-550
03-47 1249332 LINK SW SIZE 3-550
03-48 1275190 LINK SW SIZE LOW
03-50 1275192 550 PAPER CASSETTE
03-99 1246284 KIT ROLL ASSY FEED
Table 7-11. 550-Sheet Cassette Unit A4 Universal
Ref. No Code Name
