EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 473
Confidential

Duplex Unit  Stacker
Table 7-12. Duplex Unit
Ref. No Code Name
03-01-01 1275689 HSG UPPER ASSY
03-01-04 1249338 ROLL PINCH
03-01-05 1275690 HSG LOWER ASSY
03-01-07 2086981 HARNESS ASSY DUP
03-01-10 1250316 SCREW THUMB
03-01-11 1249339 SCREW HINGE
03-01-12 1275691 COVER TOP
03-01-13 1275692 LEVER LATCH RIGHT
03-01-15 1275693 LEVER LATCH LEFT
03-01-16 1249343 SPRING LATCH
03-01-17 1275694 ROLLER DUP
03-01-25 1275695 COVER LEFT
03-01-27 2082575 SWITCH DUPLEX
03-01-28 2086982 HARNESS ASSY DUP EARTH
03-01-29 2086983 MOTOR DUPLEX
03-01-31 2086984 HARNESS ASSY DUP COVER
01-32 2082576 PWBA DUPLEX
01-33 2082577 FAN DUPLEX
01-34 2026720 EXIT SENSOR
01-35 2086985 HARNESS ASSY DUP SNR
01-36 1275696 SPRING ACUTUATOR
01-37 1275697 ACUTUATOR DUP
01-40 1249348 SCREW TAPPING
01-41 1275698 COVER RIGHT
Table 7-13. Stacker
Ref. No Code Name
03-01-01 1275699 COVER ASSY OCT
03-01-02 1275700 WEIGHT
03-01-04 1275701 COVER REAR
03-01-06 2086988 MOTOR ASSY OCT
03-01-07 1275702 GEAR 45
03-01-08 1275703 GEAR 19/37
03-01-11 1275704 GEAR 19
03-01-15 1275709 ACUTUATOR FULL STACK
03-01-16 1275710 ROLL OCT LOWER
03-01-18 2082575 SWITCH DUPLEX
03-01-20 2086989 MOTOR ASSY OFFSET
03-01-22 2086990 PWBA OCT
03-01-25 2086991 HARNESS ASSY OCT 2
03-01-26 2086992 HARNESS ASSY OCT SNR
03-01-27 2086993 SOLENOID ASSY GATE
03-01-28 1275711 GEAR CAM
03-01-29 2086995 HARNESS ASSY REAR COVER
03-01-30 2021773 E.R.M. SENSOR
03-01-31 1275712 ACUTUATOR OCT
01-35 1275714 CHUTE OFFSEET ASSY
01-36 1275715 ROLL OCT UPPER
01-40 1275716 TRAY ASSY OCT
01-46 2086996 HARNESS ASSY OCT MOT
01-48 1275717 SHAFT FULL STACK
01-49 1275718 FLAPPER L
01-50 1275719 FLAPPER R
01-55 1275720 COVER S OCT
