EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 474
Confidential
ACULASER M4000N
 Main unit
Table 7-14. Main unit
Ref No Code Name
1.1.1 2118796 CONTROL PANEL
1.1.2 1490814 COVER OPEN
1.1.3 1490815 COVER REAR
1.1.4 1490816 COVER RIGHT
1.1.5 1490817 COVER FRONT
1.1.6 1490818 COVER LEFT
1.1.7 1490819 COVER TOP
1.1.8 1490820 COVER STOPPER
1.1.9 1062429 STOPPER
1.1.10 2118797 HARNESS
1.1.14 1490821 COVER EXIT 500
1.1.15 2121941 FAN MAIN 80
2.1.1 1488759 COVER CST
2.1.3 1246285 FRICTION CLUTCH
2.1.5 1403731 HOLDER RETARD
2.1.6 1488760 SPRING RETARD
2.1.7 1249109 GEAR PB L
2.1.8 1249140 GEAR BTM ONEWAY
2.1.10 1433072 PLATE ASSY BTM
2.1.11 1488761 GUIDE ASSY SD L 150
2.1.13 1490822 GUIDE ASSY SD R 150
2.1.15 1249143 GEAR LOCK ONEWAY
2.1.18 1433073 SPRING BTM UP 150
2.1.19 1249131 PLATE GEAR LOCK 150
2.1.20 1249103 GEAR PB R
2.1.21 1249132 RACK BTM LOCK 150
2.1.23 1249104 GEAR LOCK PINION
2.1.24 1249133 SPRING BTM LOCK
2.1.25 1249134 GEAR LEVER LOCK
2.1.26 1249135 LEVER BTM LOCK
2.1.27 1249137 SPRING STOPPER GEAR
2.1.28 1249136 STOPPER GEAR
2.1.32 1275140 RACK SIZE
2.1.33 1490824 HANDLE EXTENSION 150
2.1.35 1490825 GUIDE ASSY END 150
2.1.37 1275143 LINK SW SIZE 1-150
2.1.38 1275144 LINK SW SIZE 2-150
2.1.39 1275145 LINK SW SIZE 3-150
2.1.50 1488762 150 PAPER CASSETTE
2.1.99 1246284 KIT ROLL ASSY FEED
4.1.1 1488759 COVER CST
4.1.3 1246285 FRICTION CLUTCH
4.1.5 1403731 HOLDER RETARD
4.1.6 1488760 SPRING RETARD
4.1.7 1249109 GEAR PB L
4.1.8 1249140 GEAR BTM ONEWAY
4.1.10 1433072 PLATE ASSY BTM
4.1.11 1488765 GUIDE ASSY SD L 550
4.1.13 1490826 GUIDE ASSY SD R 550
4.1.15 1249143 GEAR LOCK ONEWAY
4.1.18 1433075 SPRING BTM UP 550
4.1.19 1249329 PLATE GEAR LOCK 550
4.1.20 1249103 GEAR PB R
4.1.21 1249330 RACK BTM LOCK 550
4.1.23 1249104 GEAR LOCK PINION
4.1.24 1249133 SPRING BTM LOCK
4.1.25 1275187 GEAR BTM ROCK
4.1.26 1249134 GEAR LEVER LOCK
4.1.27 1249135 LEVER BTM LOCK
4.1.28 1249137 SPRING STOPPER GEAR
4.1.29 1249136 STOPPER GEAR
4.1.36 1249331 GUIDE INDICATOR 3
4.1.40 1275140 RACK SIZE
4.1.41 1490828 HANDLE EXTENSION 550
4.1.43 1490829 GUIDE ASSY END 550
4.1.45 1249334 LINK SW SIZE 1-550
4.1.46 1249333 LINK SW SIZE 2-550
Table 7-14. Main unit
Ref No Code Name
