EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 475
Confidential
4.1.47 1249332 LINK SW SIZE 3-550
4.1.48 1275190 LINK SW SIZE LOW
4.1.50 1488763 550 PAPER CASSETTE
4.1.99 1246284 KIT ROLL ASSY FEED
5.1.6 1461456 ACTUATOR NO PAPER
5.1.12 1490832 ROLL REGI RUBBER
5.1.15 1249113 ACTUATOR A
5.1.17 1249114 ACTUATOR B
5.1.21 2082538 CLUTCH ASSY PH
5.1.23 2082538 CLUTCH ASSY PH
5.1.30 2021773 E.R.M. SENSOR
5.1.37 2122293 HARNESS ASSY TR
5.1.38 2021773 E.R.M. SENSOR
5.1.99 1246284 KIT ROLL ASSY FEED
7.1.3 2109305 GUIDE TRAY R ASSY
7.1.7 1461055 GUIDE TRAY L ASSY
7.1.9 1249171 LOCK CST L
7.1.14 1461456 ACTUATOR NO PAPER
7.1.20 2082538 CLUTCH ASSY PH
7.1.36 2122294 HARNESS ASSY TRAY 2
7.1.38 2021773 E.R.M. SENSOR
7.1.99 1246284 KIT ROLL ASSY FEED
8.1.1 2121946 ROS ASSY 45-1200
8.1.2 2086922 HARNESS ASSY ROS
8.1.5 2109310 FAN SUB
8.1.9 1249173 SPRING SL
8.1.11 2122295 INTERLOCK S/W 24V
8.1.12 2122296 INTERLOCK S/W 5V
8.1.14 1249174 LEVER GUIDE
8.1.15 1490841 GUIDE CRU LEFT
8.1.17 2122298 HARNESS ASSY FUSER 220V
8.1.18 2086923 LEVER FUSER LH
8.1.19 2122867 LEVER FUSUER RH
8.1.21 1488764 HOUSING ASSY BTR J2
8.1.22 1275222 CHUTE TRANSFER
Table 7-14. Main unit
Ref No Code Name
8.1.23 2109125 PWBA ASSY ANT
8.1.24 2109126 HARNESS ASSY ANT
8.1.25 2109127 GUIDE ASSY CRU R
8.1.29 1432839 LEVER LINK
8.1.30 1249186 LINK GEAR 3
10.1.3 2086930 CHUTE ASSY EXIT UPPER
10.1.7 1275226 LINK GATE OCT
10.1.10 1490848 ACTUATOR FULL STACK
10.1.12 1275228 ROLL EXIT
10.1.13 1275229 GEAR 21
10.1.15 2121947 MOTOR ASSY EXIT
10.1.17 1275230 GEAR 16/49
10.1.18 1275231 GEAR 25-2
10.1.19 1275232 GEAR 25-1
10.1.20 1275233 GATE OCT EXIT
10.1.22 1408638 SPRING PINCH EXIT
10.1.23 1408636 ROLLER PINCH EXIT
10.1.25 2021773 E.R.M. SENSOR
10.1.26 2021773 E.R.M. SENSOR
10.1.27 2086933 HARNESS ASSY EXIT SNR
10.1.29 1275735 CHUTE LOW ASSY
10.1.30 1408637 ROLL PINCH OCT
10.2.1 1490858 COVER REAR 500 ASSY
10.2.3 1275256 ROLL PINCH FU
10.2.4 1275257 SPRING PINCH FU
10.2.6 1275258 GATE FU
10.2.11 1490860 LEVER LATCH RIGHT
10.2.14 1275261 ROLL FU
10.2.17 1490861 LEVER GATE FU
10.2.21 1490862 COVER REAR 500
10.2.22 1490863 COVER DUP
10.2.23 1275269 STOPPER FSR
10.2.24 1493388 TRAY FU A4 ASSY
11.1.2 2121948 MAIN MOTOR45
11.1.3 1275275 GEAR ASSY HOUSING
Table 7-14. Main unit
Ref No Code Name
