EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 476
Confidential

550-Sheet Cassette Unit A4 Universal
11.1.4 1246467 SPRING RELEASE
11.1.9 1277519 GEAR 9
11.1.10 1275276 GEAR ASSY PLATE
11.1.11 1275277 FOOT
12.1.1 2122302 HARNESS ASSY LVPS
12.1.4 2109131 PWBA EXIT MOTOR
12.1.5 2121950 LVPS 220V
12.1.6 2082675 POWER SWITCH
12.1.7 2122303 INTERLOCK S/W REAR
12.1.8 2122304 HARNESS ASSY AC 220V
12.1.13 2118794 "BOARD ASSY,MAIN"
12.1.16 2086946 FFC ASSY ESS
12.1.17 2122588 HARNESS ASSY CHUTE
12.1.19 2121951 HVPS/MCU 220V
12.1.21 2122589 HARNESS ASSY FDR 1
12.1.26 2109322 HARNESS ASSY OCT 1
12.1.33 1276214 SPRING TYPE-B
12.1.34 1276215 SHIELD CONT OPTION
12.1.36 1278889 DUCT HIGH
Table 7-14. Main unit
Ref No Code Name
Table 7-15. 550-Sheet Cassette Unit A4 Universal
Ref No Code Name
20.1.17 2121954 MOTOR FEEDER
20.1.18 2082564 OPT ASSY SIZE
20.1.19 2109323 HARNESS ASSY SIZE FDR 1
20.1.22 1276213 FOOT
20.1.25 1490880 COVER RE 550
20.1.26 2109324 HARNESS ASSY FDR 5
20.1.34 2122306 PWBA FEEDER 550
20.1.35 2109325 HARNESS ASSY SIZE FDR 2
20.1.36 2109148 HARNESS ASSY CLSNR 2
20.1.37 2109326 HARNESS ASSY FDR MOT
20.1.38 1246472 JOINT FEEDER
20.1.39 1249171 LOCK CST L
20.1.5 2109142 HARNESS ASSY FDR 2
20.1.6 1246471 SPRING EARTH TOP
20.1.8 2121953 DRIVE ASSY OPT FDR 45
20.2.14 1275679 ROLL ASSY TURN
20.2.21 2082538 CLUTCH ASSY PH
20.2.22 2082538 CLUTCH ASSY PH
20.2.24 1275681 CHUTE OUT ASSY
20.2.28 1249308 ROLL PINCH TURN
20.2.31 2109329 HARNESS ASSY CLSNR 1
20.2.32 2086907 HOLDER NO PAPER SENSOR
20.2.33 2021773 E.R.M. SENSOR
20.2.6 1461456 ACTUATOR NO PAPER
20.2.99 1246284 KIT ROLL ASSY FEED
20.3.1 1488759 COVER CST
20.3.10 1433072 PLATE ASSY BTM
20.3.11 1488765 GUIDE ASSY SD L 550
20.3.13 1490826 GUIDE ASSY SD R 550
20.3.15 1249143 GEAR LOCK ONEWAY
20.3.18 1433075 SPRING BTM UP 550
20.3.19 1249329 PLATE GEAR LOCK 550
20.3.20 1249103 GEAR PB R
