EPSON EPL-N3000/AcuLaser M4000N Revision C
Appendix ASP List (Parts List) 477
Confidential

Duplex Unit
20.3.21 1249330 RACK BTM LOCK 550
20.3.23 1249104 GEAR LOCK PINION
20.3.24 1249133 SPRING BTM LOCK
20.3.25 1275187 GEAR BTM ROCK
20.3.26 1249134 GEAR LEVER LOCK
20.3.27 1249135 LEVER BTM LOCK
20.3.28 1249137 SPRING STOPPER GEAR
20.3.29 1249136 STOPPER GEAR
20.3.3 1246285 FRICTION CLUTCH
20.3.36 1249331 GUIDE INDICATOR 3
20.3.40 1275140 RACK SIZE
20.3.41 1490828 HANDLE EXTENSION 550
20.3.43 1490829 GUIDE ASSY END 550
20.3.45 1249334 LINK SW SIZE 1-550
20.3.46 1249333 LINK SW SIZE 2-550
20.3.47 1249332 LINK SW SIZE 3-550
20.3.48 1275190 LINK SW SIZE LOW
20.3.5 1403731 HOLDER RETARD
20.3.50 1488763 550 PAPER CASSETTE
20.3.6 1488760 SPRING RETARD
20.3.7 1249109 GEAR PB L
20.3.8 1249140 GEAR BTM ONEWAY
20.3.99 1246284 KIT ROLL ASSY FEED
Table 7-15. 550-Sheet Cassette Unit A4 Universal
Ref No Code Name
Table 7-16. Duplex Unit
Ref No Code Name
21.1.1 1275689 HSG UPPER ASSY
21.1.10 1250316 SCREW THUMB
21.1.11 1432031 SCREW HINGE
21.1.12 1490899 COVER TOP
21.1.13 1490900 LEVER LATCH RIGHT
21.1.15 1275693 LEVER LATCH LEFT
21.1.16 1249343 SPRING LATCH
21.1.17 1275694 ROLLER DUP
21.1.25 1490901 COVER LEFT
21.1.27 2082575 SWITCH DUPLEX
21.1.28 2086982 HARNESS ASSY DUP EARTH
21.1.29 2109331 MOTOR DUPLEX
21.1.31 2086984 HARNESS ASSY DUP COVER
21.1.32 2122308 PWBA DUPLEX
21.1.33 2121956 FAN DUP J2
21.1.34 2026720 EXIT SENSOR
21.1.35 2086985 HARNESS ASSY DUP SNR
21.1.36 1275696 SPRING ACUTUATOR
21.1.37 1275697 ACUTUATOR DUP
21.1.40 1432033 SCREW TAPPING
21.1.41 1490816 COVER RIGHT
21.1.43 1490903 SPRING FG DUP
21.1.45 1490904 COVER REAR DUP
21.1.5 2121955 HSG LOWER ASSY
21.1.7 2109330 HARNESS ASSY DUP
