3-30 Phaser 5500 Printer Service Manual
Fuser Failure - U4-7 Cold Sagging
The Fuser temperature regulation failed.
Note
Following display of this error, leave power applied for 7 minutes, then cycle
printer power. If the error reoccurs, proceed with troubleshooting procedure.
Applicable Error Code
Fuser Failure - U4-7 Cold Sagging
Fuser Thermistor Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check the Fuser installation.
Is the Fuser installed properly?
Go to Step 2. Correct the
installation.
2
For FS1 Thermistor Only.
Is the resistance across P/J131-1 and P/
J131-2 more than or equal to 3 k-ohm?
Go to Step 3. Replace the
Fuser
(
page 8-76).
3
For FS2 Thermistor Only.
Is the resistance between P/J132-1 and
P/J132-2 greater than or equal to
3 k-ohm?
Go to Step 4. Replace the
Fuser
(
page 8-76).
4
For Pressure Roller Thermistor Only.
Is the resistance across P/J133-1 and P/
J133-2 greater than or equal to
3 k-ohm?
Go to Step 5. Replace the
Fuser
(
page 8-76).
5
Check the Fuser connection.
Is P/J6 connected?
Go to Step 6. Connect P/J6.
6
Check continuity between the Fuser and
LVPS.
Is there continuity on each wire
between P/J600 <=> P/J6?
Go to Step 7. Repair the wiring.
7
Check power to the Fuser
Is there +XX V across P/JXXX (+) <=>
ground?
Replace the Fuser
(
page 8-76).
Replace the
LVPS
(
page 8-92).
