Fuji Xerox Phaser 5500 User Manual

Print-Quality Troubleshooting 5-11
Spots
Spots Troubleshooting Procedure
Actions and Questions Yes No
1. From the Main Menu, select Information, then press the
OK button.
2. Scroll to Information Pages, then press the OK button.
3. Scroll to Configuration Page, then press the OK button.
4. Inspect the print for spots. Within a 289 X 95 mm square:
■ There should be no spots larger than or equal to
0.5 mm visible on the prints.
■ There should be no more than 1 spot measuring
between 0.4 mm and 0.5 mm visible on the print.
■ There should be no more than 16 spots measuring
between 0.25 mm and 0.4 mm visible on the print.
■ Any spot measuring less than 0.25 mm is
acceptable.
Are the prints free of spots or the spots that are visible
fall within the acceptable range?
Go to "Light
(Undertoned)
Print" on
page 5-14.
Go to "Spots"
on page 5-29.
s5500-05
4

Fuji Xerox Phaser 5500 Specifications

General

Brand	Fuji Xerox
Model	Phaser 5500
Category	Printer
Language	English
