Fuji Xerox Phaser 5500 User Manual

Wiring Diagrams 10-23
Registration Transport
Engine
Logic Board
P/J403
B9
+24VDC
B10
J403
B13
B8
B3
Registration Clutch ON (L)+24VDC
P215
2
1
1
2
Registration Clutch
J104
1
2
3
Registration Sensor Paper Sensed (L)+5VDC
SG
+5VDC
P/J410
16
+24VDC
17
Takeaway Clutch ON (L)+24VDC
P204
2
1
1
2
Take Away Clutch
P/J410
12
11
J106
1
2
SG
Door B Open (H)+5VDC
Door B
Interlock Switch
J410
15
14
15
J105
1
2
3
F/O #3 Sensor Sensed (L)+5VDC
SG
+5VDC
P608
1
J608
3
2 2
3 1
+24VDC
+5VDC
+5VDC
+24VDC
s5500-222
Registration Sensor
Feed out #3 Sensor
