3-44 Phaser 5500 Printer Service Manual
Jam at E - E4-3 Exit 2 Area Jam
Paper did not pass the Exit 2 Exit Sensor located behind Door E on time.
Applicable Error Codes
Jam at E - E4-3 Exit 2 Area Jam
Jam at A - E4-5 Exit 2 Area Jam
20
Check continuity between the Exit 2 Exit
Sensor and Exit PWB.
Is there continuity on each wire
between P/J112 <=> P/J434?
Go to Step 21. Repair the wiring.
21
Check for +5 V at the Exit 2 Exit Sensor.
Is there +5 V across the sensor
connector’s P/J112-3 <=> ground?
Replace the Exit
Sensor
(
page 3-102).
Go to Step 22.
22
Check the connection between the Exit
PWB and Engine Logic Board.
Are P/J431 and P/J421 connected?
Go to Step 23. Connect P/J431
and P/J421.
23
Check continuity between the Exit PWB
and Engine Logic Board.
Is there continuity on each wire
between P/J431 <=> P/J421?
Go to Step 24. Repair the wiring.
24
Check the connection between the Exit
PWB and the LVPS.
Are P/J430 and P/J526 connected?
Go to Step 25. Connect P/J430
and P/J526.
25
Check continuity between the Exit PWB
and the LVPS.
Is there continuity on each wire
between P/J430 <=> P/J526?
Go to Step 26. Repair the wiring.
26
Check for +24 V to the Exit PWB.
Is there +24 V across P/J430-1 (+) <=>
ground?
Replace the Exit
PWB (
page 8-88).
Replace the
LVPS
(
page 8-92).
E4-1 Exit 2 Area Jam Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
