3-172 Phaser 5500 Printer Service Manual
Punch Failure - H5-3n SNR
The Punch Home Sensor is not turned On (H5-31) or Off (H5-32) within the specified
time after Punch Motor activation.
Applicable Error Codes
Punch Failure - H5-31 SNR ON
Punch Failure - H5-32 SNR OFF
11
Check Compiler Rear Tamper Motor
Harness continuity.
1. Disconnect P/J8362 and P/J8309.
2. Check for continuity at the following:
J8362B-6 <=> P/J8309-15
J8362B-5 <=> P/J8309-16
J8362B-4 <=> P/J8309-17
J8362B-3 <=> P/J8309-18
J8362B-2 <=> Non connection
J8362B-1 <=> P/J8309-19
Are these conductive?
Go to Step 12. Repair the
Compiler
Harness.
12
Check for +24 V to the Rear Tamper Motor.
Is there +24 V across J8309-16 <=>
ground on the Finisher Main PWB?
Go to Step 13. Replace the
Finisher Main
PWB
(
page 3-248).
13
Replace the Front Tamper Motor.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Punch Failure (Punch Home Sensor) Troubleshooting Reference
Applicable Parts References
■ Punch Home Sensor
■ Punch Harness
■ Punch Sensor
Harness
■ Finisher Main PWB
■ Punch Motor
■ Punch Drive Harness
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Punch P/J Locator (page 5-31)
■ Finisher Punch (2/2) Wiring (page 5-47)
■ PL25.7 Finisher Punch (page 4-56)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Tamper (Rear Tamper Home Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
