Fuji Xerox Phaser 5500

Reference A-19
Finisher Sensor/Switch Tests Menu
Tests the functionality of Finisher sensors and switches by displaying the sensor’s
current state while you manually toggle the device.
Finisher Sensor / Switch Tests
Test Action / Requirement
Door F Interlock
Sensor
Displays the status as “Open” or “Closed”.
Door G Interlock
Switch
Displays the status as “Open” or “Closed”.
Door H Interlock
Switch
Displays the status as “Open” or “Closed”.
Horizontal Transport
Entrance Sensor
Displays the status as, “With Paper” or “Without Paper”.
Horizontal Transport
Exit Sensor
Displays the status as, “With Paper” or “Without Paper”.
Transport Entrance
Sensor
Displays the Transport Entrance sensor status as, “With Paper” or
“Without Paper.”
Gate Sensor Displays status as, “With Paper” or “Without Paper”.
Buffer Path Sensor Displays the status, “With Paper” or “Without Paper” when toggled.
Upper Tray Exit
Sensor
Displays the status, “With Paper” or “Without Paper”.
Upper Tray Full
Sensor
Displays the sensor status, “Empty” or “Full”.
Compiler Exit Sensor Displays the sensor status as, “With Paper” or “Without Paper”.
Compiler Tray No
Paper Sensor
Displays the sensor state as, “With Paper” or “Without Paper”.
Side Registration
Sensor 1
Displays the sensor state, “With Paper” or “Without Paper”.
Side Registration
Sensor 2
Displays the state, “With Paper” or “Without Paper”.
Eject Clamp Home
Sensor
Displays the sensor status as, “Home” or “Not Home” when toggled.
Set Clamp Home
Sensor
Displays the sensor status as, “Home” or “Not Home” when toggled.
Punch Move Home Displays the sensor status as, “Home” or “Not Home” when toggled.
Punch Unit Move
Home Sensor
Displays the sensor status as, “Home” or “Not Home” when toggled.
Punch Home Sensor Displays the sensor status as, “Home” or “Not Home” when toggled.
Punch Front Sensor Displays the sensor status as, “Home” or “Not Home” when toggled.
