Error Messages, Codes, and Procedures 3-211
Tray Empty - No Paper in Tray 6
The Tray 6 No Paper Sensor indicates that the tray is empty.
7
Check continuity between the Tray 4-5
PWB and the Engine Logic Board.
1. Disconnect P/J541 and P/J413.
2. Check for continuity at the following:
P/J541-1 <=> P/J413-A1
P/J541-2 <=> P/J413-A2
P/J541-3 <=> P/J413-A3
P/J541-4 <=> P/J413-A4
P/J541-5 <=> P/J413-A5
P/J541-6 <=> P/J413-A6
P/J541-7 <=> P/J413-B1
P/J541-8 <=> P/J413-B2
P/J541-9 <=> P/J413-B3
P/J541-10 <=> P/J413-B4
P/J541-11 <=> P/J413-B5
P/J541-12 <=> P/J413-B6
Are these conductive?
Go to Step 8. Repair the wiring.
8
Check for +5 V to the Tray 4-5 PWB.
Is there +5 V across P/J541-5 (+) <=>
ground?
Replace the Tray
4-5 PWB
(
page 3-29).
Replace the
Engine Logic
Board
(
page 8-89).
No Paper in Tray 6 (No Paper Sensor) Troubleshooting Reference
Applicable Parts References
■ No Paper Sensor
■ Tray 6 PW B
■ Engine Logic
Board
■ Phaser 5500 Printer Options Service Manual
■ 2000-Sheet Tray 6 Feeder P/J Locator (page 5-20)
■ 2000-Sheet Tray 6 Drive Wiring (page 5-25)
■ PL22.5 Tray 6 Feeder (2/3) (page 4-26)
■ PL22.8 Tray 6 Electrical (page 4-32)
No Paper in Tray 6 (No Paper Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check Tray 6 harness connections.
Are P/JF60, JF56A, PF56A, and P/JF02
connected?
Go to Step 2. Connect and if
error persists, go
to Step 2.
No Paper in Tray 4 or 5 (No Paper Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
