Error Messages, Codes, and Procedures 3-181
Stacker Lower Tray Failure - H5-86 Side Regi SNR OFF
Either or both Side Registration Sensors do not transition within the time interval
specified (500 ms) following activation of the Punch Move Motor or the state changes
to On after the Punch Move Motor stops.
Applicable Error Code
Stacker Lower Tray Failure - H5-86 Side Regi SNR OFF
18
Check Set Clamp Clutch Harness
continuity.
1. Disconnect P/J8338B and P/J8304.
2. Check for continuity at the following:
J8338B-1 <=> P/J8304-20
J8338B-2 <=> P/J8304-22
Are these conductive?
Go to Step 19. Repair the Set
Clamp Clutch
Harness.
19
Check for +24 V to the Set Clamp Clutch.
Is there +24 V across J8304-22 <=>
ground on the Finisher Main PWB?
Go to Step 20. Replace the
Finisher Main
PWB
(
page 3-248).
20
Replace the Set Clamp Clutch.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Punch Failure (Side Registration Sensors) Troubleshooting Reference
Applicable Parts References
■ Punch Move Motor
■ Punch Drive Harness
■ Finisher Main PWB
■ Engine Logic Board
■ Side Registration
Sensors
■ Punch Sensor
Harness
■ Punch Unit Harness
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Punch P/J Locator (page 5-31)
■ Finisher Punch (1/2) Wiring (page 5-46)
■ Finisher Punch (2/2) Wiring (page 5-47)
■ PL8.1 Print Engine Electrical (page 9-40)
■ PL25.7 Finisher Punch (page 4-56)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Eject Clamp (Set Clamp Home Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
