3-150 Phaser 5500 Printer Service Manual
Exit Unit Failure - H3-n Offset Error
Failure to establish Offset Home Position on Exit1 (H3-1) or Exit 2 (H3-2).
Applicable Error Codes
Exit Unit Failure - H3-1 Offset Error
Exit Unit Failure - H3-2 Offset Error
2
Check for +24 V to the Duplex PWB.
Is there +24 V across P/J540-2 (+) <=>
ground?
Replace the
Duplex PWB
(
page 3-77).
Replace the
Engine Logic
Board
(
page 8-89).
Exit Offset Error (OCT Position Sensor) Troubleshooting Reference
Applicable Parts References
■ OCT Position
Sensor
■ Offset Motor
■ Exit PWB
■ LVPS
■ Engine Logic
Board
■ Print Engine P/J Engine Logic Board (page 10-13)
■ Print Engine P/J Laser and Exit PWB (page 10-7)
■ Print Engine LVPS Wiring (page 10-21)
■ Print Engine Exit 1 Wiring (page 10-30)
■ PL8.1 Print Engine Electrical (page 9-40)
■ Phaser 5500 Printer Options Service Manual
■ Exit 2 Plug/Jack Locator (page 5-15)
■ Exit 2 General Wiring (page 5-7)
■ PL24.2 Exit 2 Tray Guide Assembly (page 4-40)
Exit Offset Error (OCT Position Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Test the affected OCT Position Sensor.
Run the Service Diagnostics Exit 1 or 2
Offset Home Position Sensor test.
Does the sensor state change?
Go to Step 10. Go to Step 2.
2
Check the sensor connection.
Is P/J117 (Exit 1) or P/J111 (Exit 2)
connected?
Go to Step 3. Connect the
sensor.
3
Check continuity between the affected
OCT Position Sensor and the Exit PWB P/
J111 <=> P/J434 and SJ1 (Exit2) P/J117
<=> P/J423 (Exit 1).
Is there continuity on each wire?
Go to Step 4. Repair the wiring.
Incorrect Duplex Unit Installed Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
