3-242 Phaser 5500 Printer Service Manual
Close Door E - Door E is Open
The Door E Interlock Switch in Exit 2 indicates that Door E is open.
Door E Open (Door E Interlock Switch) Troubleshooting Reference
Applicable Parts References
■ Door E Interlock
Switch
■ Exit PWB
■ Engine Logic
Board.
■ Print Engine P/J Laser and Exit PWB (page 10-7)
■ Print Engine P/J Engine Logic Board (page 10-13)
■ PL8.1 Print Engine Electrical (page 9-40)
■ Phaser 5500 Printer Options Service Manual
■ Exit 2 P/J Locator (page 5-15)
■ Exit 2 Sensor/Fan Wiring (page 5-18)
■ PL24.2 Exit 2 Tray Guide Assembly (page 4-40)
Door E Open (Door E Interlock Switch) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check Door E operation.
Does Door E open and close normally?
Go to Step 2. Correct the
installation.
2
Test the Door E Interlock Switch.
Run the Service Diagnostics Door E
Interlock Switch test.
Does the sensor state change each time
the switch is pressed?
Reconnect the
Engine Logic
Board connector.
Go to Step 3.
3
Check the switch connections.
Are P/J116, P/J606B and P/J434
connected?
Go to Step 4. Connect P/J116,
P/J606B and P/
J434.
4
Check continuity between the switch and
the Exit PWB.
Is there continuity on each wire
between P/J116 and P/J434?
Go to Step 5. Repair the wiring.
5
Check for +5 V to the switch.
Is there +5 V across P/J116-2 (+)<=>
ground?
Replace the Door
E Interlock switch
(
page 3-95).
Replace the Exit
PWB (
page 8-88).
