Error Messages, Codes, and Procedures 3-73
Jam at B - C5-3 Tray 6
Paper fed from the 2000-Sheet Feeder did not reach the Print Engine’s Registration
Sensor on time.
Applicable Error Code
Jam at B - C5-3 Tray 6
11
Check the Main Harness connections.
Are the connectors PF57 and P/JF06 on
the Main Harness connected?
Go to Step 12. Connect and go
to Step 12.
12
Print a Test Print.
Does the error still occur?
Go to Step 13. Problem solved.
13
Check the Feeder Harness for continuity
1. Disconnect PF57 and JF06.
2. Check for continuity at the following:
PF57-7 <=> P/JF06-11
PF57-6 <=> P/JF06-8
PF57-5 <=> P/JF06-9
PF57-4 <=> P/JF06-10
PF57-3 <=> P/JF06-12
PF57-2 <=> P/JF06-7
Are these conductive?
Go to Step 14. Repair the Tray 6
Main harness.
14
Check Take Away Motor resistance.
Is there some amount of resistance
across F57-3/4(COM) and JF57-1/2/5/6?
Go to Step 15. Replace the Take
Away Motor
(
page 3-64).
15
Check for +24 V at the Take Away Motor.
Is there +24 V across PF06-9 <=> PF04-
2, and PF06-10 <=> PF04-2 on the Tray 6
PWB?
Go to Step 16. Replace the Tray
6 PWB
(
page 3-67).
16
Replace the Take Away Motor.
Print a Test Print.
Does the error still occur?
Go to Step 17. Problem solved.
17
Replace the Tray 6 PWB.
Print a Test Print
Does the error still occur?
Replace the
Engine Logic
Board
(
page 8-89).
Problem solved.
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
