1-4 Phaser 5500 Printer Service Manual
Parts of the Printer
Front View
Rear View
1. Standard Output Tray
2. Front Door
3. Tray 2 and 3
4. Optional Duplex Unit
5. Tray 1/MPT
6. 2000-Sheet Feeder (Tray 6)
7. 1000-Sheet Feeder (Tray 4 & 5)
8. Finisher
9. Stacker Lower Tray
10.Stacker Upper Tray
1. Parallel Connection
2. Ethernet Connection
3. USB Connection
4. Configuration Card
5. Mode Select Port
6. Serial Debug Port
7. Ground Fault Interrupt Reset
8. Printer Power Connection
9. Finisher Connection
10.1000-Sheet Feeder Connection
11.Duplex Unit Connector
2
1
4
5
6
9
3
8
7
10
5500-107
s5500-017
9
10
11
7
8
1
2
3
5
6
4
