Fuji Xerox Phaser 5500

Wiring Diagrams 10-29
Laser Assembly
Engine
Logic Board
P/J406
1
P/J140
9
ROS Valid
2 8
3 7
4 6
5 5
6 4
7 3
8 2
9 1
LD+5VDC
Power Control1 On(L)+5VDC
SG
SOS Signal
ROS VREF Out Signal
ROS Monitor
Power Control2 On(L)+5VDC
LD Enable On(L)+5VDC
LD PWB
Laser Assembly
P/J406
1
3
2
SOS Sensor
I/P Board
P/J890
2
1
4
3
P/J160
2
1
P/J170
2
1
/VD01
VD01
/VD02
VD02
P/J406
10
11
12
13
P620
4
J620
1
3 2
P/J130
5
4
3
1
2 3
1 4
M Scanner Motor
+24VDC
RTN
Scanner Motor On(L)+5VDC
Scanner Motor Clock
+24VDC
s5500-228
From
Power
