8-12 Phaser 5500 Printer Service Manual
Rear Panel Cover
PL1.2.4
1. Open the Rear Panel Cover.
2. Remove the lower boss securing the Rear Panel Cover to the printer. It is easier to
remove by pushing down the retainer of the boss.
Rear Panel Cover s5500-084
