Exit 2 Sensor/Switch Tests Menu
Test the Exit 2 sensors by manually toggling each sensor while viewing the results.
Tray 4 & 5 Sensor/Switch Tests Menu
Tests the functionality of the sensors and switches located in Trays 4 and 5 by
displaying the current state while you manually toggle the selected device.
Wait Sensor Displays “With Paper” or “Without Paper” when manually toggled.
Exit 2 Sensor/Switch Tests
Test Action / Requirement
Door E Interlock
Switch
Shows the status, “Open” or “Closed”, when manually toggled.
Exit Sensor Displays “With Paper” or “Without Paper” when manually toggled.
Exit 2 Full Stack
Sensor
Displays the status of the Full Stack sensor on the Standard Output
Tray.
Exit Offset 2 Home
Position Sensor
Displays the sensor status, “Home” or “Not Home” when toggled.
Tray 4 & 5 Sensor/Switch Tests
Test Action / Requirement
Door C Interlock Displays the status, Open or Closed, of the Door C Interlock Switch.
Tray 4 Size Sensor Displays the size indicated by the guide position.
Tray 5 Size Sensor Displays the size indicated by the guide position.
Tray 4 No Paper
Sensor
Reports “Without Paper” in the resting position, and “With Paper”
when lifted. Test the sensor by removing all paper from the tray and
reinserting it. Another method is to reach into the tray cavity and
operate the actuator manually.
Tray 5 No Paper
Sensor
Reports “Without Paper” in the resting position, and “With Paper”
when lifted. Test the sensor by removing all paper from the tray and
reinserting it. Another method is to reach into the tray cavity and
operate the actuator manually.
Tray 4 Level Sensor Reports “Up” in the resting position, and “Down” when lifted. Test
the sensor by removing all but three or four sheets of paper from the
tray and reinserting it. Another method is to reach into the tray
cavity and operate the actuator manually.
Duplex Unit Sensor/Switch Tests (Continued)
Test Action / Requirement
To Next Page
