3-170 Phaser 5500 Printer Service Manual
Stacker Lower Tray Failure - H5-2n Rear Home SNR
For H-22, the Rear Tamper Home Sensor is not turned On within 800 ms following
the Rear Tamper beginning to move to the Rear Tamper Home position. For H5-24,
the Rear Tamper Home Sensor is not turned Off in the time specified following the
Rear Tamper leaving the home position, or the Rear Tamper Home Sensor is turned
On again after the Rear Tamper Home Sensor is turned Off and the Rear Tamper stops
moving.
Applicable Error Codes
Stacker Lower Tray Failure - H5-22 Rear Home SNR ON
Stacker Lower Tray Failure - H5-24 Rear Home SNR OFF
11
Check Compiler Front Tamper Motor
Harness continuity.
1. Disconnect P/J8363B and P/J8309.
2. Check for continuity at the following:
P/J8363B-6 <=> P/J8309-10
P/J8363B-5 <=> P/J8309-11
P/J8363B-4 <=> P/J8309-12
P/J8363B-3 <=> P/J8309-13
P/J8363B-2 <=> No connection
P/J8363B-1 <=> P/J8309-14
Are these conductive?
Go to Step 12. Repair the
Compiler Front
Tamper Motor
Harness.
12
Check for +24 V to the Front Tamper Motor.
Is there +24 V across J8309-11 <=>
ground on the Finisher Main PWB?
Go to Step 13. Replace the
Finisher Main
PWB
(
page 3-248).
13
Replace the Front Tamper Motor.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Tamper (Rear Tamper Home Sensor) Troubleshooting Reference
Applicable Parts References
■ Rear Tamper Home
Sensor
■ Compiler Tray Assembly
■ Compiler Harness
■ Finisher Main PWB
■ Rear Tamper Motor
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Compiler P/J Locator (page 5-33)
■ Finisher Compiler Tray Wiring (page 5-44)
■ PL25.10 Finisher Eject (2/3) (page 4-62)
■ PL25.14 Finisher Electrical (page 4-70)
Tamper (Front Tamper Home Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
