Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-83
Jam at D - C8-6 Duplex
Paper remains at Duplex Unit’s Wait Sensor located behind Door D.
Applicable Error Code
Jam at D - C8-6 Duplex
29
Check the Main Harness for continuity.
1. Disconnect PF57 and JF06.
2. Check for continuity at the following:
PF57-7 <=> JF06-11
PF57-6 <=> JF06-8
PF57-5 <=> JF06-9
PF57-4 <=> JF06-10
PF57-3 <=> JF06-12
PF57-2 <=> JF06-7
Are these conductive?
Go to Step 30. Repair the Main
Harness.
30
Check the Take Away Motor resistance.
Is there some amount of resistance
across JF57-3/4(COM) and JF57-1/2/5/6?
Go to Step 31. Replace the Take
Away Motor
(
page 3-64).
31
Check for +24 V to the Take Away Motor.
Is there +24 V across PF06-9 <=> PF04-
3, and PF06-10 <=> PF04-3 on the PWB?
Go to Step 32. Replace the
Tray 6 PW B
(
page 3-67).
32
Replace the Take Away Motor.
Print a Test Print.
Does the error still occur?
Go to Step 33. Problem solved.
33
Replace the Tray 6 PWB.
Print a Test Print.
Does the error still occur?
Replace the
Engine Logic
Board
(
page 8-89).
Problem solved.
Jam at D (Wait Sensor) Troubleshooting Reference
Applicable Parts References
■ Wait Sensor
■ Duplex Unit PWB
■ Engine Logic
Board
■ Print Engine P/J Engine Logic Board (page 10-13)
■ PL8.1 Print Engine Electrical (page 9-40)
■ Phaser 5500 Printer Options Service Manual
■ Duplex Unit Plug/Jack Locator (page 5-12)
■ Duplex Unit Wiring (page 5-13)
■ PL23.1 Duplex Unit (page 4-34)
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
