Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-93
Jam at F - F4-26 H-X’port Exit SNR Static
Remaining paper is detected by the Horizontal Transport Exit Sensor.
Applicable Error Code
Jam at F - F4-26 H-X’port Exit SNR Static
11
Check the harness for continuity.
1. Disconnect P/J8379 of the H-’Xport
Motor, and P8372 on the H-’Xport PWB.
2. Check for continuity at the following:
P8372-13 <=> J8379-6
P8372-12 <=> J8379-4
P8372-11 <=> J8379-1
P8372-10 <=> J8379-3
P8372-15 <=> J8379-2
P8372-3 <=> J8379-5
Are these conductive?
Go to Step 12. Repair the
harness.
12
Check the H-’Xport Motor resistance.
Is there some amount of resistance
across P8379-2/5(COM) and P8379-1/3/
4/6?
Go to Step 13. Replace the H-
’Xport Motor
(
page 3-113).
13
Check for +24 V to the H-’Xport Motor.
Is there +24 V across J8372-15 <=>
J8372-7, and J8372-14 <=> J8372-7 on
the H-’Xport PWB?
Go to Step 14. Replace the H-
’Xport PWB
(
page 3-247).
14
Replace the H-’Xport Motor.
Print a Test Print.
Does the error still occur?
Go to Step 15. Problem solved.
15
Replace the H-’Xport PWB.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Jam at F (H-X’port Exit Sensor) Troubleshooting Reference
Applicable Parts References
■ H-X’port Motor
■ H-X’port Harness
■ H-X’port Exit Sensor
■ Finisher H-X’port
PWB
■ Phaser 5500 Printer Options Service Manual
■ Horizontal Transport P/J Locator (page 5-29)
■ Horizontal Transport Wiring (page 5-39)
■ Finisher Main PWB P/J Locator (page 5-35)
■ PL25.3 Horizontal Transport (2/2) (page 4-48)
■ PL25.14 Finisher Electrical (page 4-70)
Jam at A or F (H-X’port Exit Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
