Reference A-13
Exit 2 Motor Tests Menu
Test the Exit and Offset Motors in the Exit 2 Module. These tests run with the Exit.2
cover, Door E, open.
Trays 4 & 5 Motor Tests Menu
Test the Feed and Take Away motors in each tray feeder assembly.
Tray 6 Motor Tests Menu
Test the Feed/Lift and Take Away motors in Tray 6.
Exit 2 Motor Tests
Test Action / Requirement
Offset Output Motor 2
Front
Runs the Exit 2 Offset motor shifting the OCT Roller shaft forward.
Offset Output Motor 2
Rear
Runs the Exit 2 Offset motor shifting the OCT Roller shaft rearward.
Exit Output Motor 2
Forward
Runs the Exit 2 Output Motor in the forward direction for two
seconds.
Exit Output Motor 2
Reverse
Runs the Exit 2 Output Motor in reverse for two seconds.
Exit 2 Fan Runs the Exit 2 fan.
Tray 4 & 5 Motor Tests
Test Action / Requirement
Tray 4 Lift Motor Runs the Feed/Lift motor in the Lift direction for two seconds.
Tray 4 Feed Motor Runs the Feed/Lift motor in the Feed direction for two seconds.
Tray 5 Lift Motor Runs the Feed/Lift motor in the Lift direction for two seconds.
Tray 5 Feed Motor Runs the Feed/Lift motor in the Feed direction for two seconds.
Take Away Drive Runs the Take Away Drive Motor for five seconds.
Tray 6 Motor Tests
Test Action / Requirement
Tray 6 Lift Motor Runs the Feed/Lift motor in the Lift direction for two seconds.
Tray 6 Feed Motor Runs the Feed/Lift motor in the Feed direction for two seconds.
