Error Messages, Codes, and Procedures 3-131
Jam at F - F4-82 Gate SNR ON
Paper does not reach the Gate Sensor within the specified time.
Applicable Error Code
Jam at F - F4-82 Gate SNR ON
13
Check the Transport Motor resistance.
Is there some amount of resistance
across P8342-2/5(COM) and P8342-1/3/
4/6?
Go to Step 14. Replace the
Transport Motor
(
page 3-222).
14
Check for +24 V to the Transport Motor.
Is there +24 V across J8304-16 <=>
ground and J8304-18 <=> ground on the
Finisher Main PWB?
Go to Step 15. Replace the
Finisher Main
PWB
(
page 3-248).
15
Replace the Transport Motor.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Jam at F (Transport Gate Sensor ON) Troubleshooting Reference
Applicable Parts References
■ H-X’port Belts
■ H-X’port Pinch Rollers
■ Entrance Rollers
■ H-X’port Exit Sensor
■ H-X’port Harness
■ Finisher H-X’port PWB
■ Finisher Entrance Sensor
■ Main Sensor Harness
■ Finisher Main PWB
■ Transport Motor
■ Main Drive Harness
■ Transport Gate Sensor
■ Gate Sensor Harness
■ Phaser 5500 Printer Options Service Manual
■ Horizontal Transport P/J Locator (page 5-29)
■ Horizontal Transport Wiring (page 5-39)
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Sensors (1/2) Wiring (page 5-40)
■ Finisher Motors Wiring (page 5-42)
■ PL25.2 Horizontal Transport (1/2) (page 4-46)
■ PL25.3 Horizontal Transport (2/2) (page 4-48)
■ PL25.12 Finisher Transport (1/2) (page 4-66)
■ PL25.13 Finisher Transport (2/2) (page 4-68
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Static Jam at F or G (Stacker Upper Tray Exit Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
