3-130 Phaser 5500 Printer Service Manual
5
Check Main Upper Exit Sensor Harness
continuity.
1. Disconnect P/J8312 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8312A-3 <=> P/J8302A-7
J8312A-2 <=> P/J8302A-8
J8312A-1 <=> P/J8302A-9
Are these conductive?
Go to Step 6. Repair the Main
Sensor Harness.
6
Check for +5 V to the Upper Tray Exit
Sensor.
Is there +5 V across J8302A-9 <=>
J8302A-7 on the Finisher Main PWB?
Go to Step 7. Replace the
Finisher Main
PWB
(
page 3-248).
7
Check the Upper Tray Exit Sensor signal.
Does the voltage across P8302A-8 <=>
P8302A-7 on the Finisher Main PWB
change when the sensor is actuated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Upper Tray Exit
Sensor
(
page 3-226).
8
Test the Finisher Transport Motor.
Run the Service Diagnostics Finisher
Transpor t Motor Test.
Does the motor rotate normally?
Go to Step 9. Go to Step 10.
9
Test Entrance and Transport Roller drive.
Run the Service Diagnostics Finisher
Transpor t Motor Test.
Do the Entrance and Transport Rollers
rotate?
Replace the
Finisher Main
PWB
(
page 3-248).
Restore
operation.
10
Check the Finisher Transport Motor Main
Drive Harness.
Are P/J8342 and P/J8304 connected?
Go to Step 12. Connect and go
to Step 11.
11
Print a Test Print.
Does the error still occur?
Go to Step 12. Problem solved.
12
Check Main Drive Harness continuity.
1. Disconnect P/J8342 and P/J8304.
2. Check for continuity at the following:
P/J8342-1 <=> P/J8304-23
P/J8342-2 <=> P/J8304-16
P/J8342-3 <=> P/J8304-25
P/J8342-4 <=> P/J8304-27
P/J8342-5 <=> P/J8304-18
P/J8342-6 <=> P/J8304-29
Are these conductive?
Go to Step 13. Repair the Main
Drive Harness.
Static Jam at F or G (Stacker Upper Tray Exit Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
To Next Page
