Theory of Operation 2-17
Toner Dispense Assembly
The Toner Dispense Assembly operates the Toner Cartridge dispense door and moves
toner from the cartridge through a dispense tube to the Drum Cartridge.
Left
s5500-607
Transfer Roller
s5500-594
Toner Dispense
Assembly
Dispense
Tube
