Error Messages, Codes, and Procedures 3-121
Jam at H - F4-66 Compile Paper SNR Static
Paper is detected by the Compile Tray No Paper Sensor following an eject operation.
Applicable Error Codes
Jam at H - F4-66 Compile Paper SNR Static
28
Check the No Paper Sensor signal.
Does the voltage across P8309-2 <=>
P8309-1 on the Finisher Main PWB
change when the actuator is moved?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Compile Tray No
Paper Sensor
(
page 3-182).
Static Jam at H (No Paper Sensor) Troubleshooting Reference
Applicable Parts References
■ Eject Clamp Motor
■ Main Drive Harness
■ Eject Motor
■ Finisher Main PWB
■ No Paper Sensor
■ Compiler Harness
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Motors Wiring (page 5-42)
■ Finisher Clutch and Solenoids (page 5-43)
■ Finisher Compiler Tray Wiring (page 5-44)
■ PL25.9 Finisher Eject (1/3) (page 4-60)
■ PL25.10 Finisher Eject (2/3) (page 4-62)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Static Jam at H (No Paper Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Test the Eject Clamp Motor.
Run the Service Diagnostics Eject Clamp
Motor Up and Down tests.
Does the motor rotate properly?
Go to Step 6. Go to Step 2.
2
Check Eject Clamp Motor Main Drive
Harness connections.
Are P/J8339 and P/J8304 connected?
Go to Step 4. Connect and go
to Step 3.
3
Print a Test Print.
Does the error still occur?
Go to Step 4. Problem solved.
Jam at H (Compile Tray No Paper Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
