Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-109
Jam at F or H - F4-5n Compile Exit SNR OFF
Paper did not clear the Compile Exit Sensor on time.
Applicable Error Codes
Jam at F - F4-51 Compile Exit SNR OFF Jam A
Jam at F - F4-55 Compile Exit SNR OFF Jam B
Jam at F or H (Compile Exit Sensor OFF) Troubleshooting Reference
Applicable Parts References
■ Lower Exit Roller
■ Compile Exit Sensor
■ Compiler Harness
■ Main Sensor Harness
■ Finisher Main PWB
■ Main Drive Harness
■ Exit Motor
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Sensors (1/2) Wiring (page 5-40)
■ Finisher Motors Wiring (page 5-42)
■ PL25.10 Finisher Eject (2/3) (page 4-62)
■ PL25.11 Finisher Eject (3/3) page 4-64)
■ PL25.13 Finisher Transport (2/2) (page 4-68)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Jam at F (Compile Exit Sensor OFF) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check the paper path.
Open Door G.
Is the Lower Exit Roller clean, installed
correctly and roll freely?
Go to Step 2. Clean or replace
the Lower Exit
Roller.
2
Test the Compile Exit Sensor.
Run the Service Diagnostics Compile Exit
Sensor test.
Does the sensor state change?
Go to Step 11. Go to Step 2.
3
Check the Compile Exit Sensor
connection.
Are P/J8320 and P/J8391 connected?
Go to Step 5. Connect and go
to Step 4.
4
Print a Test Print.
Does the error still occur?
Go to Step 5. Problem solved.
5
Check Main Sensor Harness connections.
Are P/J8391 and P/J8302A connected?
Go to Step 7. Connect and go
to Step 6.
6
Print a Test Print.
Does the error still occur?
Go to Step 7. Problem solved.
