3-110 Phaser 5500 Printer Service Manual
7
Check Compiler Harness continuity.
1. Disconnect P/J8320 and P/J8391.
2. Check for continuity at the following:
P/J8320-3 <=> J8391B-1
P/J8320-2 <=> J8391B-2
P/J8320-1 <=> J8391B-3
Are these conductive?
Go to Step 8. Repair the
Compiler
Harness.
8
Check Main Sensor Harness continuity.
1. Disconnect P/J8391 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8391A-3 <=> J8302A-4
J8391A-2 <=> J8302A-5
J8391A-1 <=> J8302A-6
Are these conductive?
Go to Step 9. Repair the Main
Sensor Harness.
9
Check for +5 V to the Compile Exit Sensor.
Is there +5 V across J8302A-6 <=>
J8302A-4 on the Finisher Main PWB?
Go to Step 10. Replace the
Finisher Main
PWB
(
page 3-248).
10
Check Compile Exit Sensor signal.
Does the voltage across P8302A-5 <=>
P8302A-4 on the Finisher Main PWB
change when the actuator is operated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Compile Exit
Sensor
(
page 3-189).
11
Test the Exit Motor.
Run the Service Diagnostics Finisher Exit
Motor Test.
Does the motor rotate normally?
Replace the
Finisher Main
PWB
(
page 3-248).
Go to Step 12.
12
Test the Lower Exit Roller Drive.
Run the Service Diagnostics Finisher Exit
Motor CCW test.
Do the Exit Rollers rotate?
Go to Step 14. Restore operation
and go to Step
13.
13
Print a Test Print.
Does the error still occur?
Go to Step 14. Problem solved.
14
Check Exit Motor harness connections.
Are P/J8334 and P/J8304 connected?
Go to Step 16. Connect and go
to Step 15.
15
Print a Test Print.
Does the error still occur?
Go to Step 16. Problem solved.
Jam at F (Compile Exit Sensor OFF) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
