Error Messages, Codes, and Procedures 3-111
16
Check Exit Motor Harness continuity.
1. Disconnect P/J8334 and P/J8304.
2. Check for continuity at the following:
P/J8334-1 <=> P/J8304-2
P/J8334-2 <=> P/J8304-4
P/J8334-3 <=> P/J8304-1
P/J8334-4 <=> P/J8304-3
P/J8334-5 <=> P/J8304-6
P/J8334-6 <=> P/J8304-5
Are these conductive?
Go to Step 17. Repair the Main
Drive Harness.
17
Check Exit Motor resistance.
Is there some amount of resistance
across P8334-2/5(COM) and P8334-1/3/
4/6?
Go to Step 18. Replace the Exit
Motor
(
page 3-243).
18
Check for +24 V to the Exit Motor.
Is there +24 V across J8304-4 <=>
ground and J8304-6 <=> ground on the
Finisher Main PWB?
Go to Step 19. Replace the
Finisher Main
PWB
(
page 3-248).
19
Replace the Exit Motor.
Print a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Jam at F (Compile Exit Sensor OFF) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
