3-194 Phaser 5500 Printer Service Manual
Tray N Failure - H8-3, 4 Tray Size Sensor Broken
Paper size detection has failed in Tray 4 or Tray 5.
Applicable Error Codes
Tray 4 Failure - H8-3 Tray 4 Size Sensor Broken
Tray 5 Failure - H8-4 Tray 5 Size Sensor Broken
5
Check continuity between the affected
Paper Size Switch and the Engine Logic
Board.
For Tray 2:
1. Disconnect P/J109 and P/J412.
2. Check for continuity at the following:
P/J109-1 <=> P/J412-4
P/J109-2 <=> P/J412-3
P/J109-3 <=> P/J412-2
P/J109-4 <=> P/J412-1
For Tray 3:
1. Disconnect P/J110 and P/J412.
2. Check for continuity at the following:
P/J110-1 <=> P/J412-9
P/J110-2 <=> P/J412-8
P/J110-3 <=> P/J412-7
P/J110-4 <=> P/J412-6
Are these conductive?
Go to Step 6. Repair the wiring.
6
Check for +5 V to the Paper Size Switch.
For Tray 2:
Is there +5 V across J109-1 (+) <=>
ground?
For Tray 3:
Is there +5 V across J110-1 (+) <=>
ground?
Replace the Paper
Size Switch for the
affected tray
(
page 8-19).
Replace the
Engine Logic
Board
(
page 8-89).
Tray Failure (Tray 2-3 Paper Size Switch) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
