A-14 Phaser 5500 Printer Service Manual
Finisher Motor Tests Menu
Individually activate each Finisher motor. Most motor rotational tests run for two or
three seconds then stop.
Tray 6 Take Away
Motor -Slow
Runs the Take Away Motor at low speed for two seconds.
Tray 6 Take Away
Motor - Fast
Runs the Take Away Motor at high speed for two seconds.
Finisher Motor Tests
Test Action / Requirement
Horizontal Transport
Motor - Fast
Runs the Horizontal Transport motor at high speed.
Horizontal Transport
Motor - Slow
Runs the Horizontal Transport motor at low speed.
Transport Motor Runs the Transport motor.
Registration Motor-
Fast-CW
Runs the Registration motor clockwise at high speed.
Registration Motor-
Slow-CW
Runs the Registration motor clockwise at slow speed.
Registration Motor-
CCW
Runs the Registration motor counter clockwise.
Exit Motor-Fast-CW Runs the Exit motor at high speed in the clockwise direction.
Exit Motor-Slow-CW Runs the Exit motor at slow speed in the clockwise direction.
Exit Motor-CCW Runs the Exit motor in the counter clockwise direction.
Punch Unit Motor
Front
Moves the Punch forward.
Punch Unit Motor
Rear
Moves the Punch to the rear.
Punch Motor- 3 hole Performs a 3-hole punch.
Punch Motor- 2 hole Performs a 2-hole punch.
Punch Motor- 4 hole Performs a 4-hole punch.
Front Tamper Motor Provides a sub-directory that includes tests to run the Front Tamper
motor at the speed and position selected (Low Speed Outboard,
Mid Speed Outboard, High Speed Outboard, Low Speed Inboard,
Mid Speed Inboard, High Speed Inboard).
Tray 6 Motor Tests (Continued)
Test Action / Requirement
