Error Messages, Codes, and Procedures 3-61
Jam at Tray n - Feed Out #3
Paper fed from a universal tray did not reach Feed Out Sensor #3, located behind
Door B on the Print Engine Take Away Chute, on time.
Applicable Error Codes
Jam at Tray 3 - C2-2 Tray 3
Jam at Tray 4 - C3-2 Tray 4
Jam at Tray 5 - C4-2 Tray 5
15
For Trays 4 and 5 Only:
Check continuity between the Feed Out
Sensor and the Tray 4-5 PWB.
Is there continuity on each wire
between the sensor and board
Go to Step 16. Repair the wiring.
16
For Trays 4 and 5 Only:
Check for +5 V at the Feed Out Sensor.
Is there +5 V across the sensor
connector’s Pin 1 <=> ground?
Replace the
sensor.
Go to Step 17.
17
For Trays 4 & 5 Only:
Check connections between the Tray 4-5
PWB and Engine Logic Board.
Are P/J541 and P/J413 connected?
Go to Step 18. Connect P/J541
and P/J413.
18
For Trays 4 & 5 Only:
Check continuity between the Tray 4-5
PWB and the Engine Logic Board.
Is there continuity on each wire
between P/J541 <=> P/J413?
Go to Step 19. Repair the wiring.
19
For Trays 4 & 5 Only:
Check for +24 V at the Tray 4-5 PWB
Is their +24 V across P/J541-7 (+) <=>
ground?
Replace the Tray
4-5 PWB
(
page 3-29).
Replace the
Engine Logic
Board
(
page 8-89).
Jam at Tray n (Registration Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
