3-82 Phaser 5500 Printer Service Manual
21
Check the Feeder Harness for continuity.
1. Disconnect PF58 and JF56B.
2. Check for continuity at the following:
PF58-1 <=> JF56-1
PF58-2 <=> JF56-2
PF58-3 <=> JF56-3
PF58-4 <=> JF56-4
PF58-5 <=> JF56-5
PF58-6 <=> JF56-6
Are these conductive?
Go to Step 22. Repair the Feeder
harness.
22
Check the Main Harness for continuity.
1. Disconnect PF56 and JF06.
2. Check for continuity at the following:
PF56-1 <=> JF06-1
PF56-2 <=> JF06-3
PF56-3 <=> JF06-2
PF56-4 <=> JF06-6
PF56-5 <=> JF06-4
PF56-6 <=> JF06-5
Are these conductive?
Go to Step 23. Repair the Main
Harness.
23
Check resistance of the Feed/Lift Motor.
Is there some amount of resistance
across PF58-2/5 (COM) and PF58-1/3/4/
6?
Go to Step 24. Replace the
Feed/Lift Motor
(
page 3-49).
24
Check for +24 V at the Feed/Lift Motor.
Is there +24 V across PF06-3 <=> PF04-3
and PF06-4 <=> PF04-3 on the Tray 6
PWB?
Go to Step 25. Replace the Tray
6 PWB
(
page 3-67).
25
Replace the Feed/Lift Motor.
Print a Test Print.
Does the error still occur?
Go to Step 33. Problem solved.
26
Test the Take Away Motor.
Run the Service Diagnostics Tray 6 Take
Away Motor test at high speed.
Does the motor rotate normally?
Go to Step 33. Go to Step 27.
27
Check the Main Harness connection.
Are PF57 and JF06 connected?
Go to Step 29. Connect and go
to Step 28.
28
Print a Test Print.
Does the error still occur?
Go to Step 29. Problem solved.
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
