Error Messages, Codes, and Procedures 3-81
10
Test the Feed Out Sensor #6.
1. Open Door J.
2. Run the Service Diagnostics Tray 6
Feed Out Sensor test.
Does the sensor change state?
Go to Step 18. Go to Step 11.
11
Check the Feed Out Sensor #6
connections.
Is PF67 and JF54 connected?
Go to Step 12. Connect and go
to Step 12.
12
Check the Main Harness connections.
Is PF54 and JF01 connected?
Go to Step 14. Connect and go
to Step 13.
13
Print a Test Print.
Does the error still occur?
Go to Step 14. Problem solved.
14
Check the Harness for continuity.
1. Disconnect PF67 and JF54.
2. Check for continuity at the following:
PF67-1 <=> JF54-3
PF67-2 <=> JF54-2
PF67-3 <=> JF54-1
Are these three conductive?
Go to Step 15. Repair the
Harness.
15
Check the Main Harness continuity.
1. Disconnect PF54 and JF01.
2. Check for continuity at the following:
JF54-1 <=> JF01-3
JF54-2 <=> JF01-2
JF54-3 <=> JF01-1
Are these three conductive?
Go to Step 16. Repair the Main
Harness.
16
Check for +5 V to the Feed Out Sensor #6.
Is there +5 V across PF01-3 <=> PF04-2
on the Tray 6 PWB?
Go to Step 17. Replace the Tray
6 PWB
(
page 3-67).
17
Check the Feed Out Sensor #6 signal.
Does the voltage across JF01-2 <=>
PF04-2 on the Tray 6 PWB change when
the Feed Out Sensor is actuated?
Go to Step 33. Replace the Feed
Out Sensor #6
(
page 3-63).
18
Test the Tray 6 Feed/Lift Motor.
Run the Service Diagnostics Feed Motor
test.
Does the Feed Motor rotate normally?
Go to Step 26. Go to Step 19.
19
Check the harness connections.
Are PF58 and PF56 on the Feeder and
Main Harnesses, and JF06 on the PWB
connected?
Go to Step 21. Connect and go
to Step 20.
20
Print a Test Print.
Does the error still occur?
Go to Step 21. Problem solved.
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
